Ampleon雷達功率放大器

發布時間：2024-03-21 11:00:54     瀏覽：905

Ampleon功率放大器產品廣泛應用于雷達系統，包括脈沖雷達、移動無線電、通信、廣播、工業、科學和醫療等。Ampleon的雷達功率放大器具有高效率、高功率、堅固耐用等特點，能夠滿足雷達系統在復雜環境和高性能要求下的工作需求。此外，這些功率放大器還具備出色的熱性能和可靠性，保證了雷達系統的長期穩定運行。

產品選型：

Type NumberDie technologyPackageFmin(Mhz)Fmax(Mhz)PL1db(W)PL1db(dBm)Vds(V)Nd(%)Gp(dB)
BLA9G1011L-300LDMOSSOT502A10301090317.055.032.064.821.5
BLA9G1011L-300GLDMOSSOT502F10301090317.055.032.064.821.5
BLA9G1011LS-300LDMOSSOT502B10301090317.055.032.064.821.5
BLA9G1011LS-300GLDMOSSOT502E10301090317.055.032.064.821.5
BLA9H0912L-1200PLDMOSSOT539A96012151200.060.850.060.019.0
BLA9H0912L-250LDMOSSOT502A9601215250.054.050.060.022.0
BLA9H0912L-250GLDMOSSOT502F9601215250.054.050.060.022.0
BLA9H0912L-700LDMOSSOT502A9601215700.058.550.062.020.0
BLA9H0912L-700GLDMOSSOT502F9601215700.058.550.062.020.0
BLA9H0912LS-1200PLDMOSSOT539B96012151200.060.850.060.019.0
BLA9H0912LS-1200PGLDMOSSOT1248C96012151200.060.850.060.019.0
BLA9H0912LS-250LDMOSSOT502B9601215250.054.050.060.022.0
BLA9H0912LS-250GLDMOSSOT502E9601215250.054.050.060.022.0
BLA9H0912LS-700LDMOSSOT502B9601215700.058.550.062.020.0
BLA9H0912LS-700GLDMOSSOT502E9601215700.058.550.062.020.0
BLL9G1214L-600LDMOSSOT502A12001400600.057.832.060.019.0
BLL9G1214LS-600LDMOSSOT502B12001400600.057.832.060.019.0
BLP0427M9S20LDMOSTO-270-2F-110270020.043.028.063.019.0
BLP0427M9S20GLDMOSTO-270-2G-110270020.043.028.063.019.0
BLS9G2729L-350LDMOSSOT502A27002900350.055.428.050.014.0
BLS9G2729LS-350LDMOSSOT502B27002900350.055.428.050.014.0
BLS9G2731L-400LDMOSSOT502A27003100400.056.032.047.013.0
BLS9G2731LS-400LDMOSSOT502B27003100400.056.032.047.013.0
BLS9G2735L-50LDMOSSOT1135A2700350045.046.532.048.012.0
BLS9G2735LS-50LDMOSSOT1135B2700350045.046.532.048.012.0
BLS9G2934L-400LDMOSSOT502A29003400400.056.032.043.012.0
BLS9G2934LS-400LDMOSSOT502B29003400400.056.032.043.012.0
BLS9G3135L-115LDMOSSOT1135A31003500115.050.632.049.014.0
BLS9G3135L-400LDMOSSOT502A31003500400.056.032.043.012.0
BLS9G3135LS-115LDMOSSOT1135B31003500115.050.632.049.014.0
BLS9G3135LS-400LDMOSSOT502B31003500400.056.032.043.012.0
BLU9H0408L-800PLDMOSSOT539A400800800.059.050.067.520.5
CLL3H0914L-700GaNSOT502A9001400750.058.850.065.017.0
CLL3H0914LS-700GaNSOT502B9001400750.058.850.065.017.0

Ampleon公司是一家領先的功率半導體供應商，專注于研發和銷售高頻、高功率的射頻功率和數據放大器解決方案，產品線豐富，廣泛應用于無線基礎設施、雷達系統等多個領域。

立維創展專業代理Ampleon產品，擁有價格優勢，歡迎咨詢。
